2 ton fuel forklift
|
mode |
CPC20 |
||||
|
characteristic |
Power form |
diesel oil |
|||
|
rated load(KG) |
2000 |
||||
|
Load center(mm) |
500 |
||||
|
Lifting height(mm) |
3000 |
||||
|
Free lifting height(mm) |
100 |
||||
|
Fork size （Length×width×thickness）(mm) |
1070x122x40 |
||||
|
Gantry inclination angle front/rear(Deg) |
6/12 |
||||
|
minimum turning radius(mm) |
2190 |
||||
|
Ground clearance(mm) |
Gantry |
120 |
|||
|
frame |
130 |
||||
|
Height of roof protection frame(mm) |
2160 |
||||
|
Front overhang(mm) |
450 |
||||
|
performance |
Maximum driving speed(Km/h) |
19 |
|||
|
Maximum lifting speed(mm/s) |
500 |
||||
|
maximum traction force（KW） |
17 |
||||
|
Max Gradeability% |
20 |
||||
|
size |
entire length（mm） |
Fork with cargo |
3600 |
||
|
No fork |
2530 |
||||
|
Full width(mm) |
1160 |
||||
|
Height of forks during lifting (with shelves) |
4220 |
||||
|
Gantry landing height(mm) |
2060 |
||||
|
chassis |
tire |
front wheel |
7.00-12-12PR |
||
|
rear-wheel |
6.00-9-10PR |
||||
|
wheelbase(mm) |
1600 |
||||
|
Track width(mm) |
970/970 |
||||
|
dead-weight（kg） |
3530 |
||||
|
drive |
storage battery（V/Ah） |
12/80 |
|||
|
engine
|
model |
xinchaiC490BPG |
|||
|
rated power（kw/r.p.m） |
40/2650 |
||||
|
Torque（nm/r.p.m） |
165/1800 |
||||
|
Cylinder diameter ×stroke（mm） |
90x105 |
||||
|
Number of cylinders |
4 |
||||
|
Displacement(L) |
2.7 |
||||
|
Mailbox capacity |
60 |
||||
|
Gear position (front/rear) |
2/2Manual Shift |
||||
Standard configuration:
Xinchai 490 diesel engine
Zhongnan Mechanical Transmission
Two section three meter gantry
Zhengxin tires
Fork 1070mm
Toolbox/Repair Kit
Performance Introduction:
Assembling a new diesel engine with strong performance, energy conservation, and environmental protection
Zhongnan gearbox, smooth shifting and comfortable operation
Linde steering bridge Bengbu hydraulic cylinder, silent and insulated hood
Integrated water tank cover plate, beautiful and durable
Hongchang high-quality portal frame steel, with long service life and less deformation
Genuine new tires with strong wear resistance and good shock absorption effect,
Optional configuration:
New diesel engine, all diesel engine, Jiangling engine
Imported Isuzu engine, imported Mitsubishi engine
Mechanical transmission, manual hydraulic transmission, electromagnetic hydraulic transmission
Two 3.0-meter, 3.3/3.5/4.0/4.5/5.0-meter gantry frames
Two 3.0-meter, 3.3/3.5/4.0/4.5/5.0-meter fully free gantry frames
Three 4.5-meter, 4.8/5.0/5.5/6.0/6.5-meter fully free gantry
Zhengxin pneumatic tire/solid tire, Chaoyang pneumatic tire/solid tire, environmentally friendly solid tire
Different accessories can be assembled according to different goods, such as side shift and cotton bag clamp
Paper roll clips, cardboard box clips, etc
